Model |
IT-389 |
IT-589 |
Q’ty of Electrolytic Plate |
3 pieces plates |
5 pieces plates |
Material of Electrolytic Plate |
Platinum-titanium plate, made by KOBE STEEL |
Platinum-titanium plate, made by KOBE STEEL |
Voltage |
AC110V / AC220V 50/60HZ |
AC110V / AC220V 50/60HZ |
Power Consumption |
Max. 180W |
Max. 230W |
Inlet Water Pressure |
0.9~5.0 kg/cm² |
0.9~5.0 kg/cm² |
Electrolysis Method |
Continuous electrolysis (built-in flow meter) |
Continuous electrolysis (built-in flow meter) |
Water Flow Rate |
Ideal water processing: 2 Liters/min. (based on inlet water pressure 1kg/cm²) Water flow rate: 3 Liters/min. (based on inlet water pressure 2kg/cm²) |
Ideal water processing: 2 Liters/min. (based on inlet water pressure 1kg/cm²) Water flow rate: 3 Liters/min. (based on inlet water pressure 2kg/cm²) |
Display |
pH, ORP, water flow rate, working status, clean, pure, alkaline, acidity and filter service life |
pH, ORP, water flow rate, working status, clean, pure, alkaline, acidity and filter service life |
Cleaning |
Automatic cleaning for 10 seconds after each use of alkaline water And manual cleaning only if Alkaline water consumption is up to 30 liters |
Automatic cleaning for 10 seconds after each use of alkaline water And manual cleaning only if Alkaline water consumption is up to 30 liters |
Electolysis Levels |
4 Alkaline levels, 1 Neutral level and 1 Acid level |
4 Alkaline levels, 1 Neutral level and 2 Acid levels |
pH Adjustment |
Each electrolysis level has 20 segments for pH adjustment (based on water source quality in different areas) |
Each electrolysis level has 20 segments for pH adjustment (based on water source quality in different areas) |
Filter Material |
Activated carbon fiber (ACF), made in USA and approved by NSF certificate |
Activated carbon fiber (ACF), made in USA and approved by NSF certificate |
Filter Service Life |
About 12,000 liters (depend on water resource quality) |
About 12,000 liters (depend on water resource quality) |
Safety Protection Device |
Current protection & Alarm only if drinking Acid water |
Current protection & Alarm only if drinking Acid water |
Dimension & Weight |
H 310mm x W 220mm x D 125mm, Approx. 4.1 kg |
H 310mm x W 220mm x D 125mm, Approx. 4.3 kg |
pH Value (based on source water quality) |
5~10 |
4.5~11 |
ORP Value (based on source water quality) |
-650mv (Max.) |
-850mv (Max.) |
